Project Description
About this Project
This organ features the following:
- Portativ-style console
- Drawknobs for stop controls
- 1 rebuilt manual keyboard
- standard wiper contact system
- Rosewood naturals with maple/white sharps
- New thumb pistons by Syndyne
- Expression knob on nameboard
- Pitch knob on nameboard
- New solid state switching, console control, combination action
- Fold-down music desk
- On/Off switch
- Transposer +6/-6
- New organist’s bench
- Complete MIDI Implementation:
- MIDI In/Out/Thru ports
- Sequencer In/Out ports
- Auxiliary stereo audio input ports – 1/4″ jacks
Stop List
| TEACART | 1. | Bourdon | 16′ |
| Expressive | 2. | Basson | 16′ |
| Manual I | |||
| 3. | Principal | 8′ | |
| 4. | Gedeckt (BASS) | 8′ | |
| 5. | Gedeckt (TREBLE) | 8′ | |
| 6. | Gemshorn | 8′ | |
| 7. | Gemshorn Celeste | 8′ | |
| 8. | Prestant | 4′ | |
| 9. | Flute (BASS) | 4′ | |
| 10. | Flute (TREBLE) | 4′ | |
| 11. | Twelfth | 2 2/3′ | |
| 12. | Fifteenth | 2′ | |
| 13. | Larigot | 1 1/3′ | |
| 14. | Cornet III (TREBLE) | ||
| 15. | Cromorne (BASS) | 8′ | |
| 16. | Cromorne (TREBLE) | 8′ | |
| 17. | Tremulant | ||
| 18. | Harp | ||
| 19. | Celesta | ||
| 20. | Zimbelstern | ||
| COMBINATION | Multiple Level Capture Combination Action | ||
| ACTION | 10 | Banks of Memory | |
| Memory Bank Up | |||
| Memory Bank Down | |||
| 10 | Levels of Memory per Bank | ||
| Memory Level Up | |||
| Memory Level Down | |||
| General Combinations | |||
| MIDI BASS | |||
| MIDI TREBLE | |||
| General Cancel | |||
| Set | |||
