Project Description

GREAT 1. Violone 16′
2. Diapason 8′
Unenclosed 3. Principal 8′
Manual II 4. Clarabel Flute 8′
5. Bourdon 8′
6. Gamba 8′
7. Octave 4′
8. Hohlflute 4′
9. Twelfth 2 2/3′
10. Fifteenth 2′
11. Seventeenth 1 3/5′
12. Mixture IV 1 1/3′
13. Trombone 16′
14. Tromba 8′
15. Clarinet (Solo) 8′
16. Tuba Mirabilis (Solo) 8′
17. Pontifical Trumpet 8′
18. Tremulant


SWELL 1. Lieblich Gedeckt 16′
Expressive 2. Geigen Principal 8′
Manual III 3. Salicional 8′
4. Voix Celeste 8′
5. Harmonic Flute 8′
6. Gedeckt 8′
7. Flauto Dolce 8′
8. Flute Celeste 8′
9. Principal 4′
10. Flute Octaviante 4′
11. Nasard 2 2/3′
12. Harmonic Piccolo 2′
13. Tierce 1 3/5′
14. Plein Jeu IV 2′
15. Carillon III 1 3/5′
16. Posaune 16′
17. French Trumpet 8′
18. Cornopean 8′
19. Oboe 8′
20. Vox Humana 8′
21. Pontifical Trumpet (Great) 8′
22. Clairon 4′
23. Glockenspeil
24. Tremulant
25. Swell to Swell 16′
26. Swell Unison Off
27. Swell to Swell 4′


CHOIR 1. Dulciana 16′
Expressive 2. Violin Diapason 8′
Manual I 3. Violin Celeste 8′
4. Stopped Diapason 8′
5. Dulciana 8′
6. Unda Maris 8′
7. Principal 4′
8. Rohrflute 4′
9. Violina 4′
10. Nazard 2 2/3′
11. Flautino 2′
12. Larigot 1 1/3′
13. Cymbal III 1′
14. Corno Basso 16′
15. Corno d’Amore 8′
16. Cromorne 8′
17. Tuba Mirabilis (Solo) 8′
18. Pontifical Trumpet (Great) 8′
19. Tremulant
20. Harp
21. Celesta
22. Choir to Choir 16′
23. Choir Unison Off
24. Choir to Choir 4′


SOLO 1. Grand Diapason 8′
Expressive 2. Flauto Mirabilis 8′
Manual IV 3. Doppelflute 8′
4. Gamba 8′
5. Gamba Celeste 8′
6. Octave 4′
7. Orchestral Flute 4′
8. Grand Fourniture V 2′
9. Ophicleide 16′
10. Bass Clarinet 16′
11. Tuba Mirabilis 8′
12. Tuba 8′
13. Pontifical Trumpet (Great) 8′
14. French Horn 8′
15. English Horn 8′
16. Orchestral Oboe 8′
17. Quint Tromba 5 1/3′
18. Tuba Clarion 4′
19. Chimes
20. Tremulant
21. Solo to Solo 16′
22. Solo Unison Off
23. Solo to Solo 4′


STRING 1. Viol 16′
Expressive 2. Cello Flat 8′
Floating 3. Cello 8′
4. Cello Sharp 8′
5. Orchestral Violin Flat 8′
6. Orchestral Violin 8′
7. Orchestral Violin Sharp 8′
8. Muted Violin Flat 8′
9. Muted Violin 8′
10. Muted Violin Sharp 8′
11. Dulciana 8′
12. Dulciana Sharp 8′
13. Dulcet 4′
14. Dulcet Sharp 4′
15. Vox Humana 8′
16. Tremulant
17. String to String 16′
18. String Unison Off
19. String to String 4′
STRING 20. Contra Gamba 32′
PEDAL 21. Viol 16′
Unenclosed 22. Viol Sharp 16′
23. Viol 8′
24. Dulciana 8′


PEDAL 1. Contra Bass 32′
Unenclosed 2. Contra Bourdon 32′
3. Principal 16′
4. Subbass 16′
5. Violone (Great) 16′
6. Lieblich Gedeckt (Swell) 16′
7. Dulciana (Choir) 16′
8. Octave 8′
9. Gemshorn 8′
10. Bourdon 8′
11. Choral Bass 4′
12. Nachthorn 4′
13. Mixture IV 2 2/3′
14. Contra Bombarde 32′
15. Contra Fagotto (Swell) 32′
16. Bombarde 16′
17. Ophicleide (Solo) 16′
18. Posaune (Swell) 16′
19. Fagotto (Swell) 16′
20. Pontifical Trumpet (Great) 8′
21. Tuba (Solo) 8′
22. Tromba 8′
23. Clarion 4′
24. Chimes (Solo)


COUPLERS 1. Great to Pedal 8′
2. Swell to Pedal 8′
3. Swell to Pedal 4′
4. Choir to Pedal 8′
5. Choir to Pedal 4′
6. Solo to Pedal 8′
7. Solo to Pedal 4′
8. String to Pedal 8′
LCD Display Screen
9. Swell to Great 16′
10. Swell to Great 8′
11. Swell to Great 4′
12. Choir to Great 16′
13. Choir to Great 8′
14. Choir to Great 4′
15. Solo to Great 16′
16. Solo to Great 8′
17. Solo to Great 4′
18. Swell to Choir 16′
19. Swell to Choir 8′
20. Swell to Choir 4′
21. Solo to Choir 16′
22. Solo to Choir 8′
23. Solo to Choir 4′
24. String on Great
25. String on Swell
26′ String on Choir
27. String on Solo
28. All Swells to Swell
29. Great/Choir Exchange
30. String Reverse Swell Expression
